How do you program PGM outputs on a DSC alarm system?
Matthew Barrera
Published Feb 19, 2026
How do you program PGM outputs on a DSC alarm system?
How to Program PGM Outputs on a DSC Alarm
- Enter installer programming mode by typing in “*8” and then your installer’s code.
- Type in “009” on the keypad to enter the PGM output option programming mode.
- Push the “#” key and then type “501” on your keypad to change PGM1’s attributes.
How do you disarm a DSc alarm system?
DSC Alarm System (PC1616 / PC1832 / PC1864) Quick User Guide Arming & Disarming the System Arming (Turning on) Close all sensors (i.e. close doors and windows). The Ready ( ) indicator should be on. Arm the system using either of the methods below. Arming Method #1 : Enter your access code.
How to program a DSc powerseries neo alarm system?
Please try again later. Join Jason of Alarm System Store as he takes you through a tutorial of the programming of a DSC PowerSeries NEO alarm system. He will go through the steps of how to program, using the HS2LCDENG keypad, zones, door delay times, and other settings that are essential for daily operation of the system.
How to program a DSc 1832 alarm system?
Here is how I programmed it and the order I went through: 1 Enroll the keypads 2 Switch to normally-closed loops (non-resistive circuits) 3 Program the zones 4 Cancel the telephone system (as it is monitored via the Internet) 5 Set the partitioning for expanded zones 6 Check the devices 7 Reset the master code 8 Reset the installer code (victory)
How do I change the entry delay in DSC?
The entry delays need to be between 30 seconds and 255 seconds. The exit delay must be between 45 seconds and 255 seconds. Press *8-installer code to go into programming. Enter 005. The system will then want a two digit partition number. Enter 01. First, enter the 3 digit entry delay 1 in seconds. Then, the 3 digit entry delay 2 in seconds.
What makes up a DSc home security system?
Your DSC Security System is made up of a DSC control panel, one or more keypads and various sensors and detectors. The control panel, which is a metal cabinet, will be mounted out of the way in a utility closet or in the basement. The metal cabinet contains the system electronics, fuses and back up battery. Identify your security system by keypad.
How to program DSC power series 1616, 1832 and 1864 alarm system?
Hi, Ryan here with alarmsystemstore.com to show you on how to program your DSC PowerSeries 1616, 1832 or 1864 alarm system. So let’s get right to it, let’s go to my table and let’s program the system. Now, you’ve got your system all wired up, and it’s ready to be programmed.
The entry delays need to be between 30 seconds and 255 seconds. The exit delay must be between 45 seconds and 255 seconds. Press *8-installer code to go into programming. Enter 005. The system will then want a two digit partition number. Enter 01. First, enter the 3 digit entry delay 1 in seconds. Then, the 3 digit entry delay 2 in seconds.
What is the installer code for DSC power?
You will then be asked to enter Installer code .. Enter 5555 The keypad should beep and then ask you for ‘Section’ again .. Enter 999 again NOTE: If using an LED or PK5501 keypad, you will not see a display or any numbers during your programming. You have to listen for the beeps.
