How do you program zones on a DSC panel?

How do you program zones on a DSC panel?

To program your zone definitions, you must:

1. Enter Programming by pressing ” * 8 + Installer Code “
2. Enter Section 001 (Section 001 is used for Zones 1 – 16 only…
3. Now you will enter Zone 1’s 2-digit definition.
4. The system will triple beep, and now you will enter zone 2’s definition.

How do I enable DLS mode on my keyboard?

3.9 Downloading Options

1. Enter a System Master code and press [9].
2. Use the keypad arrow keys (< >) to scroll to the display “Enable DLS. Window.” Press [*]. Downloading will be enabled for one hour.
3. To exit the menu, press [#].

What is FTC trouble?

FTC Trouble – Fail to Communicate When a DSC home alarm is beeping for this condition, it means that the panel was unable to call the central station. This could be a result of no phone line as described above, in which case fixing the line will clear this condition as well.

How do I reset my security panel?

You can reset your alarm system by powering it down and then powering it back on. This is what is known as a power reset. To power down the system, the backup battery must be disconnected, and the transformer must be unplugged. Then reconnect the battery and transformer to power it back on.

Which is audio interface module for DSC pc5010?

(See Escort5580 Installation Manual.) The PC5928 Audio Interface module is a simple way to incorporate paging, intercom, baby listen-in and door answer to the PC5010 control panel. The module also has built-in two-way voice capability for central station (See Section 5.30 “Audio Interface Module”).

How many keypads do I need for a pc5010?

The PC5010 continuously monitors a number of possible trouble conditions including: A maximum of eight (8) keypads can be connected to the control panel and can be any combination of the following listed. Different keypads (with function keys) can be used for different size systems; 8 zone, 16 zone and 32 zone.

How many zones can a DSc pc5010 have?

Different keypads (with function keys) can be used for different size systems; 8 zone, 16 zone and 32 zone. Eight zone expander module can be used to increase the number of zones on the system. Up to 3 modules can be connected to increase the system zones to a maximum of 32.

Do you need a transformer for DSC pc5010?

The LINKS1000 Cellular Communicator provides an efficient, cost-effective method for adding cellular back up. The unit comes in its own cabinet with antenna and requires a separate battery and transformer (See Section 5.26 “LINKS1000 cellular communicator”). Several different cabinets are available for the PC5010 modules.

(See Escort5580 Installation Manual.) The PC5928 Audio Interface module is a simple way to incorporate paging, intercom, baby listen-in and door answer to the PC5010 control panel. The module also has built-in two-way voice capability for central station (See Section 5.30 “Audio Interface Module”).

The PC5010 continuously monitors a number of possible trouble conditions including: A maximum of eight (8) keypads can be connected to the control panel and can be any combination of the following listed. Different keypads (with function keys) can be used for different size systems; 8 zone, 16 zone and 32 zone.

Where can I find pc5010 programming worksheets online?

PC5010 Programming Worksheets Title PC5010 Programming Worksheets Author Technical Manuals Online! Subject Created Date 10/11/1997 10:48:39 AM

Different keypads (with function keys) can be used for different size systems; 8 zone, 16 zone and 32 zone. Eight zone expander module can be used to increase the number of zones on the system. Up to 3 modules can be connected to increase the system zones to a maximum of 32.
