How do you program zones on DSC 1616?

How do you program zones on DSC 1616?

How do I program a hardwired zone on the DSC 1616, 1832, and 1864 systems?

1. Enter programming.
2. Enter the appropriate section for the zone(s) you’re programming.
3. Once in that programming section each zone, in order, will have a 2-digit zone definition.

How do I bypass a zone on my DSC alarm?

How to Bypass a Zone on a DSC Power Series Security Alarm Panel

1. The System Must be disarmed prior to proceeding.
2. Press the * Key.
3. Press the 1 Key.
4. Use the > key to scroll to the zone you wish to bypass.
5. Press the * Key on the appropriate zone.
6. A “B” should appear next to the zone when the system is bypassed.

How to programming a DSc 1832 alarm or re-programming it?

I have 24 zones on my system provided by the 8 default zones on the PC1832 and the 16 additional zones from the two additional PC5108 expanders. Zones 9-24 need to be told to be in partition 1. This should show each zone being added into the partition as you enter 1, 2, 3, 4, 5, …

How many zones does a DSc 1832 alarm need?

Partitioning was the one step in the process that was initially confusing for me. You have to partition the zones above eight be in the same partition as the other zones. I have 24 zones on my system provided by the 8 default zones on the PC1832 and the 16 additional zones from the two additional PC5108 expanders.

Can a home assistant program a DSc alarm?

I have a DSC alarm at my house (a PC1832) and I want to use Home Assistant to work with it. I purchased the IT-100 board and then decided I wanted to expand it a bit further to include more zones.

What is the installer code for DSC power?

You will then be asked to enter Installer code .. Enter 5555 The keypad should beep and then ask you for ‘Section’ again .. Enter 999 again NOTE: If using an LED or PK5501 keypad, you will not see a display or any numbers during your programming. You have to listen for the beeps.

Which is the installer code in DSC power?

You will hit *85555 which by default is the installer code. Some people consider it programming code. I’m going to enter section 001. This section is where you would list the definitions for all your zones. 001 is Zones 1-16. Zone 17 starts in section 002 and so forth.

How to program a zone on the DSC 1616, 1832?

If you reach the last zone in that section, you will automatically exit back out. Enter the appropriate section for the zone (s) that you are programming. 202 is for zones 1-8. 203 is for zones 9-16. 204 is for zones 17-24. Etc. You will now use numbers 1-8 to turn on/off the corresponding zone (s).

How many alarm zones do you need in DSC power series?

If you are using 17 or more, but less than 24 zones, use programming section 204 (add 16 to each numbered zone to get that zone. Example: 1, 2, 3, 4, 5 would be zones 17, 18, 19, 20, 21) In our Sample Alarm, we are only using four (4) zones.

How do I program a hardwired zone on the DSC?

Etc. You will now use numbers 1-8 to turn on/off the corresponding zone (s). If the number is on the screen it is on and vice versa. So if you are wanting to turn on zone 15 you would enter section 203. In that section, 7 corresponds to zone 15.
