Is the scantronic 9448 plus an end station?

Is the scantronic 9448 plus an end station?

The 9448ES is an end station version designed for domestic and small commercial installations. In the 9448+ the control panel comprises a single printed circuit board, with microprocessor electronics, mounted in a Polycarbonate casing with a hinged lid.

What is the difference between The 9448 + and 9448es?

INTRODUCTION The 9448+ and 9448ES Alarm Control Panels are fully programmable 7 zone control panels with Full and Part Set, designed for domestic installations. The 9448ES is an end station version designed for domestic and small commercial installations.

Can you add a keypad to The 9448 control panel?

Option to add SD1, TSD2 and SD-GSM speech dialler to create a communicating system. Choose between including a built-in keypad (9448EUR-90) or an external keypad (the 9448EUR-95 – see image) dependent on the site or building. Providing greater flexibility on your installations. The ability ad add up to 2 users to the control panel.

Are there 7 closed circuits on the Eaton 9448?

The 9448 has 7 closed circuits (zone 7 is pre-programmed as entry/exit) and was designed to meet basic residential intruder detection requirements – being quick to install and simple to use.

Why is my scantronic 9448 alarm not working?

The 9448 like most panels can be programmed to silence sounders after a pre-set time. This is to prevent noise nuisance. What has probably happened is that the alarm has activated via the panic button, the panel has timed out (it is supposed to) then the user has entered her code which has disarmed the system.

INTRODUCTION The 9448+ and 9448ES Alarm Control Panels are fully programmable 7 zone control panels with Full and Part Set, designed for domestic installations. The 9448ES is an end station version designed for domestic and small commercial installations.

Where to download engineering guides for scantronic 9448?

Professional alarm installers can download engineering and installation guides for the Scantronic 9448 on our installer portal MyScantronic. Need product support? Need product support?

What’s the default access code for The 9448 +?

1. Apply mains to the control panel. The green power LED lights and the internal sounder will sound. Ignore any other lights. 2. Key-in the factory default user access code: 1234. The internal sounder stops. Ignore any other lights. 3. Key-in 0 then ENTER followed by the factory default engineer access code: 7890.
